Block Cameras ME-330 Ultra HD LVDS Encoder – Triple Stream, Low Power, Pro Imaging 1080p

ME-330 Spec Sheet

The Block Cameras ME-330 is a high-performance HD encoder engineered for professional imaging and security environments. Designed with an LVDS input and triple streaming capability, it supports H.265/H.264/MJPEG compression to deliver crystal-clear 1080p video at 30fps with exceptional bandwidth efficiency. Its ONVIF Profile S compliance and integrated network support for IPv4/IPv6 ensure seamless operation across a wide range of surveillance, broadcast, and industrial systems.

Compact and efficient, the ME-330 HD Encoder measures just 42×42 mm and consumes a maximum of 3 W, making it ideal for embedded or OEM applications. With microSD storage up to 2 TB (optional), UART/RS485 PTZ control, and low-latency streaming, this encoder provides dependable performance in mission-critical deployments from factory automation to advanced monitoring systems.

Features:

• Triple Streaming – 3× H.264/H.265 + 1× JPEG
• HD Resolution – 1920×1080 @ 30fps
• Efficient Compression – H.265/H.264/MJPEG
• LVDS Input – 4/8 lanes via 30‑pin micro coax
• ONVIF & CGI Support – Profile S compliant
• MicroSD Storage – up to 2 TB (optional)
• Low Power – Max 3 W consumption
• UART/PTZ – RS485, PELCO “D” protocol

Applications:

• Security Systems
• Industrial Imaging
• Machine Vision
• Surveillance Cameras
• Embedded Systems
• PTZ Control
