CIS DCC-4KZM 4K UHDTV, x18 AF Zoom, 1/1.8" CMOS, 3G-SDI/HD-SDI Rolling Shutter Camera

DCC-4KZM Spec Sheet

The CIS DCC-4KZM is a premium 4K UHDTV camera module equipped with an x18 auto-focus zoom lens, designed for exceptional imaging performance. Featuring CIS's proprietary Clairvu™ ISP technology, this camera offers superb image quality with high-speed processing, supporting functions such as auto exposure (AE), auto white balance, color correction, edge enhancement, noise reduction, and gamma control. It fully complies with BT.2020 and BT.2100 (HLG) standards for vibrant color reproduction and dynamic range.

Ideal for critical applications like broadcasting, remote-operated vehicles (ROV), traffic surveillance, medical imaging, and printing inspection, the CIS DCC-4KZM ensures reliability and precision in demanding environments. Its versatile interfaces and genlock functionality support seamless integration with advanced imaging systems.

Features:

• 4K UHDTV 60p resolution
• 3G SDI / HD SDI interface
• x18 auto-focus zoom lens
• CIS original ISP Clairvu™ technology
• RS-232C & RS-422 control interfaces
• Genlock support with 3-values analog or black burst
• LTC time code support
• Edge enhancement and 3D noise reduction
• Compliant with BT.709, BT.2020, and BT.2100 (HLG) standards

Applications:

• Broadcasting
• Remote vehicles
• Traffic monitoring
• Medical imaging
• Printing inspection
• Life sciences
