CIS SCM-2M1 2MP USB3 AI Smart Camera with NXP i.MX 8M Plus

SCM-2M1 Spec Sheet
CIS Brochure
CIS Catalog

The CIS SCM-2M1 is a compact 2MP AI smart camera designed for embedded vision, robotics, machine vision, intelligent traffic, UAV/drone systems, medical imaging, surveillance, and industrial inspection applications. Featuring NXP Semiconductor’s i.MX 8M Plus application processor and a 1/2.6" global shutter CMOS sensor, the SCM-2M1 delivers reliable image capture with onboard processing capability for both rule-based vision tasks and edge AI workflows.

Built around the AR0234 color global shutter image sensor, the SCM-2M1 captures 1920 x 1200 resolution video at up to 30 fps. Global shutter performance helps reduce motion distortion, making this camera well suited for moving objects, automation lines, mobile robots, traffic monitoring, and high-speed inspection environments.

The integrated NXP i.MX 8M Plus processor enables smart camera functionality for object recognition, object tracking, edge AI inference, and embedded image processing. With a USB 3.0 interface, M12 lens mount, lightweight 80 g body, and optional support for HDMI and 1000BASE-T Ethernet through an interface board, the SCM-2M1 provides flexible integration for OEM vision systems, AI camera platforms, and compact industrial imaging designs.

Key Features:
• 2MP AI smart camera for embedded vision and machine vision applications
• NXP i.MX 8M Plus high-performance application processor
• Supports rule-based image processing and edge AI workflows
• Ideal for object recognition, object tracking, and smart vision systems
• 1/2.6" AR0234 color global shutter CMOS sensor
• 1920 x 1200 effective pixel resolution
• Up to 30 fps at maximum resolution
• USB 3.0 interface for high-speed image transfer
• Optional HDMI and 1000BASE-T Ethernet support with interface board
• M12 lens mount for compact embedded lens integration
• Lightweight 80 g design for robotics, UAV, and OEM applications
• Compact 65 x 48 x 44 mm body size
• Designed for robotics, AI vision, inspection, intelligent traffic, medical, surveillance, and automation systems

Applications:
The CIS SCM-2M1 is ideal for:
• Robotics vision systems
• UAV and drone imaging
• AI edge camera applications
• Object recognition and object tracking
• Machine vision inspection
• Industrial automation
• Intelligent traffic monitoring
• Medical imaging devices
• Embedded surveillance systems
• OEM smart camera development
• Mobile robots and autonomous systems
• Compact AI vision platforms

Why Choose the CIS SCM-2M1?
The CIS SCM-2M1 combines compact industrial camera hardware with onboard AI processing capability. Its NXP i.MX 8M Plus processor allows developers and system integrators to move image processing closer to the camera, helping reduce system complexity, improve response time, and support edge-based vision decisions. The 2MP global shutter sensor helps capture fast-moving scenes without rolling shutter distortion, while USB3, optional HDMI, optional Gigabit Ethernet, and M12 lens support make it flexible for a wide range of embedded and industrial vision designs.

Specifications
