CIS VCC-HD30ZME1 Full HD, 30x Zoom, 1/3" CMOS, 3G-SDI/HD-SDI Rolling Shutter Camera

VCC-HD30ZME1 Spec Sheet

The CIS VCC-HD30ZME1 is a premium Full HD color camera module featuring an integrated 30x auto focus zoom lens and high-performance 1/3 type CMOS sensor. Engineered for professional-grade imaging, it delivers exceptional clarity at up to 1080/60p resolution via both 3G-SDI and HD-SDI outputs, supporting a wide range of broadcast and surveillance applications. Its advanced “Clairvu” Image Signal Processor technology ensures vivid, noise-free video and reliable auto focus, even in challenging environments.

Designed for seamless integration and flexible control, the VCC-HD30ZME1 supports RS-232C remote operation and GenLock synchronization. On-screen display settings and low-light performance make this module the ideal choice for demanding vision, security, and industrial projects requiring high image fidelity and robust connectivity.

Features:

• 1/3 type CMOS sensor for Full HD video
• CIS “Clairvu” image signal processor
• 30x optical zoom with auto focus
• Multi-format SDI output (3G-SDI, HD-SDI)
• GenLock for precise sync
• RS-232C remote control capability
• OSD menu for easy settings
• Low-light sensitivity

Applications:

• Broadcast Production
• Industrial Inspection
• Security Surveillance
• Medical Imaging
• Traffic Monitoring
