KT&C KLU64-L (KLU64L) LWIR Thermal Block Camera – 640x480, 17μm, CVBS/BT656/LVDS, 9Hz/30Hz Output

KLU64-L Spec Sheet

The KT&C KLU64-L is a compact thermal block camera module built for embedded systems, OEMs, and advanced system integrators. At its core is a 640x480 resolution uncooled LWIR microbolometer sensor with a 17μm pixel pitch, enabling pixel-accurate thermal imaging (307,200 temperature data points) and exceptional sensitivity in the 8–14 μm spectral range. With high thermal accuracy and NETD performance, the KLU64-L supports frame rates of 9Hz or 30Hz (selectable at manufacture), making it suitable for both real-time video and static image capture environments.

This versatile thermal module features multiple output formats—CVBS, BT656, and LVDS—for seamless integration into both legacy analog and modern digital systems. Engineered for performance in embedded applications, the KLU64-L includes configurable image processing options like AGC, NUC, mirror/flip, and image filtering. A 10-color palette selection enhances contrast visualization, and RS-485 OSD control enables remote menu access for analog setups. With a fast <5-second startup, wide -30°C to 60°C operating temperature, and flexible lens pairing options, the KLU64-L delivers industrial-grade performance in a compact thermal block format.

Features:

• 640 x 480 LWIR sensor with 17μm pitch
• Uncooled microbolometer technology
• Frame rate: 9Hz or 30Hz (selectable)
• Video output: CVBS, BT656, LVDS
• 8–14 μm spectral sensitivity
• Pixel-level thermal data (307,200 points)
• 10-color thermal palette options
• Configurable image settings: AGC, NUC, mirror, flip, filtering
• RS-485 menu control (analog)
• Wide operating range: -30°C to +60°C
• <5 seconds boot time
• Compatible with manual or motorized athermal lenses

Applications:

• OEM Thermal Solutions: Embedded thermal imaging in custom systems
• Industrial Monitoring: Detect overheating and equipment faults
• Security Integration: Enhanced perimeter surveillance in darkness
• Automotive Testing: Analyze engine and component heat profiles
• Building Diagnostics: Locate insulation loss and HVAC issues
• Defense Systems: Covert surveillance in low-visibility zones
• Oil & Gas Inspections: Identify thermal anomalies in field operations
• Research & Development: Analyze temperature distributions in test setups
